Bambu Lab PA6-GF Filament
Product Features
- Built to Last
- Dimensional Stability
- Exceptional Thermal Properties
- Chemical Resistance
- Smooth Surface and More Colors
- Diameter: 1.75mm +/- 0.03mm
Choose your colour, weight and package from the available NEX3D options. Refills require a compatible reusable spool. Printed models and display props are examples and are not included.
PA6-GF
· Built to Last · Dimensional Stability · Exceptional Thermal Properties · Chemical Resistance · Smooth Surface and More Colors
Built to Last
Bambu PA6-GF is exceptionally strong and durable due to reinforced glass fibers, making it the perfect choice for prints that need to withstand heavy use and resist bending or breaking. * Note: The printed part achieves better toughness after exposure to moisture.
Dimensional Stability
PA6-GF boasts unparalleled dimensional stability thanks to its glass fiber reinforcement, minimizing warping in comparison to standard PA filaments. Print with precise dimensions, even in the most intricate geometries.
Exceptional Thermal Properties
PA6-GF boasts a high heat deflection temperature and superior dimensional stability, enabling it to retain its mechanical properties even under elevated temperatures. This makes it ideal for demanding industrial and automotive applications.
Chemical Resistance
PA6-GF offers excellent resistance to chemicals, oils, and many kinds of solvents, ensuring long-term performance in challenging environments.
Smooth Surface and More Colors
Bambu PA6-GF filaments are compatible with the Bambu AMS system, ready to print in multi-color. The special surface texture also blurs the layer lines, providing a smooth surface quality.
Parameters Comparison
| PA6-GF | PA6-CF | PAHT-CF | |
|---|---|---|---|
| Composition | PA6, glass fiber | PA6, carbon fiber | PA12 and other long-chain PA, carbon fiber |
| AMS Compatibility | YES | NO | YES |
| Toughness (Impact Strength - XY, dry state) | 27.2 kJ/m² | 40.3 kJ/m² | 57.5 kJ/m² |
| Toughness (Impact Strength - XY, wet state) | 55.8 kJ/m² | 57.2 kJ/m² | 62.3 kJ/m² |
| Strength (Bending Strength - XY, dry state) | 120 MPa | 151 MPa | 125 MPa |
| Strength (Bending Strength - XY, wet state) | 71 MPa | 95 MPa | 115 MPa |
| Layer Strength (Bending Strength - Z, dry state) | 51 MPa | 80 MPa | 61 MPa |
| Layer Strength (Bending Strength - Z, wet state) | 33 MPa | 45 MPa | 49 MPa |
| Stiffness (Bending Modulus - XY, dry state) | 3670 MPa | 5460 MPa | 4230 MPa |
| Stiffness (Bending Modulus - XY, wet state) | 2120 MPa | 3560 MPa | 3640 MPa |
| Layer Adhesion (Impact Strength - Z, dry state) | 4.1 kJ/m² | 15.5 kJ/m² | 13.3 kJ/m² |
| Heat Resistance（HDT, 0.45 MPa, Dry State) | 182 ℃ | 186 ℃ | 194 ℃ |
| Saturated Water Absorption Rate (25 °C, 55% RH) | 2.56% | 2.35% | 0.88% |
RFID for Intelligent Printing
All printing parameters are embedded in RFID, which can be read through Bambu Lab's AMS (Automatic Material System).
Printing Tips
1.Accessory Compatibility
Not compatible with Cool Plate SuperTack, Hotend with Stainless Steel Nozzle 0.2 mm, Liquid Glue, and AMS lite.2.Drying Recommendations
As this filament is highly moisture-absorbent, please place any unused filament in a sealed container with desiccant immediately, and dry thoroughly before printing. For more details, please refer to: Printing tips for Engineering materials on WIKI.3.Warping Prevention Tips
To minimize warping, avoid printing large-sized high-infill-density models. Use enclosed printers and ensure the build plate is properly applied with glue for better print adhesion before printing.4.Post-processing Tips
- We recommend removing the support structures within 2 hours after printing to prevent them from sticking after absorbing moisture. If sticking occurs, dry the model to ease the removal.
- Placing the printed part in a convection oven set between 80 to 130 degrees Celsius for 5 to 12 hours can further enhance the strength and rigidity of the print. Note: The effectiveness of this process depends on the structure, size, and conditions of the printed model. Some models may warp or deform after annealing. For more details, please refer to: Work after Printing Finished on WIKI.
5.Safety Tips
- This product is a glass fiber reinforced filament that may produce fine fiber debris during use, post-processing, or contact with rough or fractured surfaces, posing a risk of mechanical skin punctures or foreign body irritation. To ensure safety, please avoid rubbing or touching rough edges and cross-sections with bare hands; it is highly recommended to wear gloves when loading or unloading the filament, as well as during cutting, sanding, or other post-processing operations, while using additional protective equipment as required by your specific working conditions.
- Please store the filament in a cool, dark, and dry environment away from direct sunlight and high temperatures.
- Please keep filament and any broken fragments out of reach of infants, children, and pets to prevent swallowing or choking.
- Please print this filament in a well-ventilated area, or install an effective air filtration or exhaust system.
- As this filament is not food-grade, please avoid using finished prints for food storage or contact.
