Bambu Lab H2S

Your Personal Manufacturing Hub

Get the Highlights

AI Detection 23 Sensors & 3 Cameras

340×320×340 mm³ Large Volume

＜ 50 μm Motion Accuracy

20,000 Times/Sec Extrusion Torque Regulation

Up to 30% Faster Print Speed

10W 455nm Laser Cutting

65 °C Active Heated Chamber

Auto Venting Filament Drying

Your Go-To Personal Manufacturing Hub

•

  3D Printing

• Multi-Color
  3D Printing

• 3D Printing

• Multi-Color
  3D Printing

•

  Laser
  Cutting

•

  Digital
  Cutting

• Multi-Color
  3D Printing

• 3D Printing
• Digital
  Cutting

Accuracy That Works for You

Correct Mechanical Deviations Even the printer comes out of the factory with superb accuracy, mechanical wear and variances over time are inevitable—but now, first time in the industry , there’s a solution.With the Vision Encoder⁽¹⁾, the H2S achieves distance-independent motion accuracy under 50 μm —thinner than a human hair. During calibration, it automatically compensates for mechanical drift, ensuring consistent precision and peak performance over time. One Print. Perfect Fit. Bambu Lab's Auto Hole/Contour Compensation² minimizes printing tolerances, delivering machine-shop-level precision for hole dimensions. Design fit-critical parts with confidence—integrate shafts, bearings, and fasteners without trial and error. Post-print assembly has never been easier. Ready for Engineering Filaments Featuring a 350 °C hotend and a 65 °C actively heated chamber, it supports the entire Bambu filament lineup—from PLA and PETG to PC and PPA. With closed-loop fan control and precise thermal management, the H2S minimizes warping and deformation while improving layer adhesion. Build large, high-performance parts that are as functional as they are strong. 350 °C Hotend 65 °C Heated Chamber

Even Surfaces, Crisp Edges H2S uses both the sensing capability of its servo motor on the extruder and the high-resolution eddy current sensors on the nozzle to precisely control extrusion by measuring nozzle pressure and calibrating PA parameters for each filament, improving surface smoothness and edge sharpness.

Precision in Motion Active Vibration Compensation neutralizes micro-vibrations and resonance in real time, enabling premium print quality at higher speeds.

Print Functional Designs

RC Plane: PLA Tough+

Go-Kart Frame: PAHT-CF

Handbag: TPU for AMS

Seed Starter: PA6-GF

Intelligence That’s Got Your Back

20,000 Checks Per Second Closed-Loop Feedback, Real-Time Control Bambu Lab’s proprietary PMSM servo system enables 20 kHz resistance and position sampling to dynamically modulate electromagnetic torque vectors. It stabilizes extrusion and actively detects grinding⁽³⁾ or clogs in real time.

Filament grinding Clogging 23 Sensors + 3 Cameras Each Potential Risk Has Its Own Detector

Vision System Feeding Thermal Control Safety With AI-driven real-time monitoring, the vision system detects clumping, spaghetti and filling chute as they happen, helping prevent failed prints before they start. This same vision system powers advanced features like Live Spatial Alignment, allowing precise laser and cutting calibration, and Vision Encoder technology, which enhances positional accuracy. Filament-path sensors work in unison to monitor feeding speed and position, detect filament tangles and grinding risks, track filament mileage and spool usage, and ensure tool readiness across the AMS, buffer, cutter, and feeding paths, making sure every tool is in place and every move is under control. Five NTC temperature sensors are strategically placed across the nozzle, heatbed, and chamber. Paired with integrated airflow sensors, the system actively monitors and adjusts internal temperatures and circulation, maintaining the ideal print environment through real-time feedback control. The H2S features five flame sensors, front-door and top-cover sensors, and emergency stop button to form a complete safety system. It detects fire risks, monitors enclosure alignment, and allows instant shutdown when needed—protecting your projects and your workspace at all times. Pre-Flight Checklist by AI Prior to each operational cycle, the H2S vision system initiates a comprehensive pre-flight checklist: Chamber Integrity Scan – Detects debris across the entire print surface. Hardware Configuration Audit – Instantly identifies build plate properties.

Flap Switch Airflow & Filtration System 3D Printing & Laser Cutting. 3 Modes, All-in-One

High-Temp Printing

Chamber sealed. Internal air recirculates through the Air Filter and the heater to stabilize high-temp conditions. Print large engineering parts without warping.

Low-Temp Printing

Top Vent opens to bring in cool air, while maintaining a filtered exhaust⁴. Print PLA and PETG without opening the door, and handle overhangs and bridging with ease.

Laser Cutting/Engraving

Top Vent and Filter Switch Flap open. Fumes are channeled efficiently to the ventilation system, keeping your workspace safe and clean.

Bigger. Faster. Better.

Maximum Volume. Maximum Productivity. With a build volume of 340×320×340 mm³ , the H2S offers the largest print space among all Bambu Lab printers. Your Vision. Fully Realized in One Print .

120% Larger Build Volume Than the X1 Carbon

Full Scale Printing Print bigger, with fewer plates Top Speed. More Reliable Than Ever. Bambu Lab’s proprietary PMSM⁽⁵⁾ servo extrusion system delivers 67% more extrusion force , providing solid support to high flow⁽⁶⁾ printing. Paired with up to 1000 mm/s toolhead speed and up to 20,000 mm/s² acceleration, your H2S can finally go full throttle— cutting your printing time by up to 30%⁽⁷⁾ —while maintaining top-tier quality. DynaSense Extruder PMSM servo extruder delivers up to 10kg of extrusion force—67% more than regular stepper motors, delivering the strongest support for high-flow printing.

1 day 7 hours 12.3% Faster Than X1C

1 day 1 hour 11.2% Faster Than X1C

6 days 22.2% Faster Than X1C

Cut. Engrave. Draw.

Compact. Capable. All in One.

Live Spatial Alignment Top-down BirdsEye camera⁽⁸⁾ and onboard toolhead camera enable Live Spatial Alignment, letting you preview the toolpath directly on your material with 0.3 mm accuracy. What you see is what you get.

Auto Arrangement Bambu Suite automatically arranges your project shapes to make the most of every sheet—smart, efficient, and effortless.

10W 455nm Laser Power Slice through up to 5 mm plywood, acrylic, or PU with ease—clean, fast, and precise.

Air Assist Air Assist keeps your lines crisp by blowing away smoke and char while cooling the surface—preventing soot buildup and beam distortion for sharp, clean results.

Digital Cutting Effortlessly cut through paper, vinyl, PU leatherette, and more—clean, accurate, and ready to apply.

Drawing Use the drawing module to automate linework, sketches, or handwritten notes—precise, repeatable, and hands-free. Not a Toolkit. A Production-Ready Platform.

• Laser
  Cutting

• Laser
  Cutting
• Laser
  Engraving

• Laser
  Cutting

• Laser
  Cutting
• Laser
  Engraving

• Digital
  Cutting

• Digital
  Cutting

Protected Inside and Out

Safety, Built In

Laser Safety Window Five Flame Sensors Flame-Retardant Chamber Emergency Stop Shields your eyes from the 455 nm laser beam while keeping your workspace clear and visible. Advanced sensors continuously monitor for fire risks. If an issue is detected, a loud buzzer and mobile alert⁹ notify you immediately—so you can act fast and stay safe. Constructed with fire-resistant materials throughout, the chamber provides passive protection for added safety. Immediately halt operations if something feels off—giving you full control and added peace of mind. Connectivity, By All Means. Privacy, By Design. The H2S offers seamless cloud connectivity for convenient remote control from any device. For security-sensitive applications, it also delivers complete offline functionality, ensuring physically isolated operation. Users can control the printer, send files, and upgrade firmware—no internet required. Additionally, Developer Mode unlocks MQTT port access, empowering developers and integrators to connect third-party components and custom software with ease.¹⁰

Accessible. Comfortable. Made to Last.

Quick-Swap Nozzle Swap nozzles in seconds—no tools, no hassle. Whether you're switching materials or upgrading to a different nozzle size, the redesigned hotend makes it easy and intuitive, even for first-time users. Quiet by Design With Active Motor Noise Canceling and specialized air duct noise-reduction technology, the H2S operates below 50 dB ¹¹. Print overnight or in shared spaces without disrupting your environment.

All-Metal, Die-Cast Body The integrated die-cast aluminum alloy chassis delivers a sturdy, stable structure that provides a rigid foundation for high-speed, large-format printing, while minimizing accuracy loss caused by micro-twisting.

Multi-Color Printing and Drying, All-in-One

AMS 2 Pro Learn More

AMS HT Learn More Electro-Magnetic Air Vent Automated venting facilitates dehumidification during drying and airtight sealing for weeks of quality printing. Auto-Rotate Drying During the drying process, the filament spools rotate automatically to provide more even drying. RFID Sync AMS 2 Pro uses RFID to auto-match drying settings for Bambu official filaments, no manual input needed.

Endless Models to Print

MakerWorld Over a Million Models at Your Fingertips

MakerLab AI Assisted 3D Modeling Tools, Bring Your Vision to Life

Maker's Supply Go-To Source for Parts that Bring 3D Prints to Life

Integrated Ecosystem, End-to-End Support

Software Ecosystem Control & Browse From Any Device, Anywhere

Bambu Lab Academy Master Your Printer with Easy-to-follow Lessons

Bambu Lab Wiki Find Answers to Every Printing Problem

H2S Specs

¹ To ensure the heatbed quickly reaches the needed temperature, the printer will maintain maximum power for about 3 minutes.² When the printer's protection is complete and properly working, the printer and laser module work as a class 1 laser product. Expand table Download PDF

FAQ

1. Does the H2S support laser and cutting functions? It supports 10W laser and cutting but does not support 40W laser. 2. Can a non-laser H2S be upgraded to a laser H2S? Yes. The upgrade kit and its installation guide will be available some time after the product launch. Note that the upgrade kit uses an external air pump, which differs in installation structure from the built-in air pump. It must be installed externally and connected to the machine via an air tube. The upgraded printer has the same functionality and processing performance as the laser version. 3. Can the H2S be upgraded to an H2D? No, it is recommended to choose the model that suits your needs when placing an order. 4. Is the H2S compatible with the first-generation AMS or AMS lite? The first-generation AMS is fully plug-and-play compatible with the H2S for multi-color printing but does not support AMS drying. Due to fundamental differences in the feeding mechanism and buffer structure, the H2S does not support AMS lite. 5. How many AMS 2 Pro and AMS HT units can the H2S support, and how many colors can it print? The H2S supports up to 4 AMS 2 Pro and 8 AMS HT units, totaling 12 units with 24 filament slots, enabling up to 24-color printing. 6. Are the hotend and silicone sock of the H2S compatible with the H2D or A1? The H2S hotend and silicone sock are compatible with the H2D. While structurally similar to the A1 hotend, they are not fully compatible. For optimal print quality, we strongly recommend not using the A1 hotend on H2 series printers. Using an H2 series hotend on an A1 printer is feasible, but it requires the H2 series silicone sock. 7. Are the H2S and A1 series tool heads the same? Can the components on the tool head be shared with the A1 series? The H2S tool head features a completely new design, with optimized and upgraded components, including the extruder motor, filament drive wheel, hotend heating assembly, and cooling fan. As a result, the components on the H2S tool head are not compatible with the A1 series, except for the cutter blade. 8. Are the build plates of the H2S and H2D compatible? Yes, they are compatible. 9. Does the H2S support motion accuracy calibration, and is the calibration plate from my previously purchased H2D compatible? It supports motion accuracy calibration, and the H2D calibration plate is compatible. 10. The AMS 2 Pro connects to the printer via a 6-pin interface. What are the two remaining 4-pin interfaces on the back of the H2S printer used for? The two 4-pin ports on the back are reserved for future expansion accessories. For example, to upgrade a non-laser version of the printer to a laser version, one of these ports can be used to connect an external air pump. 11. Does the H2S come with a standard USB drive, and what functions are affected without one? What are the USB drive specifications? The package does not include a standard USB flash drive. You can still initiate printing normally without a USB, as the printer has built-in storage space to run print files. However, without a USB inserted, the following functions will be affected: 1. The recording and time-lapse photography functions can't be turned on; 2. Printing cannot be initiated through the LAN; 3. Print files cannot be sent to the machine for storage through the Bambu Studio; 4. Log files cannot be exported; USB requirements: USB2.0 protocol or above (actual minimum write speed needs to be greater than 10MB/s), supported file formats are FAT32 and exFAT. and the printer only supports mounting one USB, and cannot connect multiple USB via a USB hub. 12. What precautions or recommendations are there for printing TPU with the H2S? Due to TPU’s flexible nature, which can cause issues during feeding and printing, we’ve created a dedicated wiki guide for TPU printing. Following the guide ensures smooth TPU printing. 13. What precautions should be taken when using the laser function? Laser processing involves high-energy beams that may interact with flammable materials. Never leave the machine unattended during laser operation, ensure no flammable or explosive items are nearby, and refer to the Laser Safety Document for detailed safety guidelines. 1. Vision Encoder: Vision Encoder needs to be purchased separately on the Bambu Lab Store. 2. Auto Hole/Contour Compensation: Auto Hole/Contour Compensation must be enabled in Bambu Studio and requires the use of designated Bambu filaments. 3. Filament grinding detection on the DynaSense Extruder may vary depending on filament type. 4. Filter Mode for low-temperature printing is optional and will be available in Q4 2025. 5. Permanent Magnet Brush-less Servo Motor 6. High Flow Hotend are optional equipment and can be purchased from the official store. 7. When using Bambu Lab PLA Basic to print a 200×200×200 mm cube with 15% infill, the printing time can be reduced by up to 30% compared to Bambu Lab X1C. Actual time savings may vary depending on the model, infill, and filament used. 8. The laser and digital cutting functions are all controlled and visualized through Bambu Suite. Live Spatial Alignment is enabled by the BirdsEye Camera. The BirdsEye Camera comes standard with the H2S Laser Edition, or can be added via the Laser Upgrade Kit. 9. Push notifications require the use of Bambu Handy and cloud connectivity. 10. Due to safety protocol, Developer mode cannot be enabled when using Laser and Cutting functions. 11. Background noise: 40 dB; Test distance: 1 m 12. The go-kart frame shown in the picture is merely a component of the complete vehicle. Its usability and durability are limited by the overall design and construction of the vehicle. It cannot be used on the road until permission is obtained from the local relevant authorities. When conducting any operations, please strictly abide by the applicable local laws, regulations and safety standards to avoid risks or damages. 13. Creator projects are provided for illustrative purposes only. Bambu Lab does not endorse, and disclaims any representations or warranties regarding creator projects, including, without limitation, the safety, marketability, or usability of any 3D printed works based on such projects. See our Terms of Service for more information. 14. Ensure that a person is always present to closely monitor the machine throughout the laser engraving and cutting process. For individuals with special conditions or medical issues, please follow medical advice. For safety instructions regarding laser use, refer to the Laser Module Safety Guidelines Wiki and the Laser Safety Document. 15. All product data for the H2S, such as PMSM extrusion force improvement and model print times, is based on Bambu Lab’s internal testing. Actual results may vary due to individual product differences, user habits, and environmental conditions. Please refer to actual usage for reference. 16. Big thanks to everyone who created these amazing projects: Crimson Shadow, Sword of the Dark Knight, Shadowforged Armor @sarwtin; Pacific Clipper @Rarecho Studio; CyberTrack @CyberBrick™; Truck, Sport Car @SophieBigRat @jinghai; MODCASE HYPER @HaydnBao; Fishcaster-Lite Electric Guitar @user_2955528674 (翻滚吧咸鱼); Storage Toolbox @schuylab; Standard Gridfinity Bin Set @Finneas; Go-Kart @2040085396 (大琢磨); "Growing Taller" Small Bag @ricky.svg; Self Watering Seed Starter @Meyui; Small FPV Aircraft @LaoYan FPV; Classic Roadster @21CNCStudio; Pen Holder @yanribing; Folding Wooden Box @woodbear; Round Box @brandon8747; Candy Carrying Tricycle @garagem 167; Floral Keepsake Box @MetaImi; Football Helmet @animuL67; Side Table @AEKI; Mini Catmaw - CyberBrick Edition @polymech3d; The Grand Budapest Hotel @雅杰不加班
